Side Outlet Roof Drain with Overflow

Please call us at (800) 658-2473 for pricing and availability.
Product information
Product Drawings Side Outlet Roof Drain with Overflow PDF Drawing
Side Outlet Roof Drain with Overflow CAD Drawing
Compliance

Side outlet roof drain made of strong 20 ounce copper. Seamless flashing and drain basin. Separate drainage connection for overflow application. Comes with strong ABS Cyclolac dome strainer. 2", 3", and 4" sizes available. Long lasting and affordable drains by Thunderbird Products are easy to install!

  • Area roof drain with built in overflow drain
  • 20 ounce copper, 10" diameter seamless basin
  • Sandblasted flashing for great waterproofing adhesion
  • Separate drainage connection for overflow application
  • 2", 3", or 4" bronze no hub fitting
  • ABS dome strainer
  • Manufactured in the USA by Thunderbird Products

Note on Fittings: Two types of fittings are available. A threaded adapter fitting is used primarily with 2" PVC pipe applications. The threads on the bronze fittings are male and can be attached to a threaded female PVC adapter. A no hubfitting is the standard fitting used in the industry. With this fitting a rubber coupling is used to connect the drain to the drainage pipe.

Part Numbers
RDCBHZ2NH 2" No-Hub Side Outlet Roof Drain with Overflow
RDCBHZ2NHCL 2" No-Hub Side Outlet Roof Drain with Center Line Overflow
RDCBHZ2NHCR 2" No-Hub Side Outlet Roof Drain with Overflow with Optional Clamping Ring
RDCBHZ2TA 2" Male Threaded Side Outlet Roof Drain with Overflow
RDCBHZ3NH 3" No-Hub Side Outlet Roof Drain with Overflow
RDCBHZ3NHCL 3" No-Hub Side Outlet Roof Drain with Center Line Overflow
RDCBHZ3NHCR 3" No-Hub Side Outlet Roof Drain with Overflow with Optional Clamping Ring
RDCBHZ3TA 3" Male Threaded Side Outlet Roof Drain with Overflow
RDCBHZ4NH 4" No-Hub Side Outlet Roof Drain with Overflow
RDCBHZ4NHCL 4" No-Hub Side Outlet Roof Drain with Center Line Overflow
